AE-SGP Industrial Borescope

Industrial inspection equipment

Overview

The AE-SGP is a high-performance industrial borescope (endoscope) system designed for precise visual inspection of internal components, machinery, pipelines, and confined industrial spaces. Engineered for reliability and advanced inspection, this system enables non-destructive testing (NDT) and internal condition assessment without dismantling equipment.

Equipped with a 1MP HD camera probe with 360° full articulation, optical fiber illumination, and flexible insertion tube, the system provides clear and detailed inspection even in complex and hard-to-reach environments. The 6-inch HD display with touch interface and multiple connectivity options ensures real-time monitoring, recording, and analysis on-site.

With interchangeable probes, multiple diameter options (0.95mm to 6mm), and customizable lengths up to 6 meters, the AE-SGP adapts to a wide range of industrial applications including automotive inspection, aerospace maintenance, power plants, manufacturing units, and pipeline inspection.

Designed for Indian industrial conditions, this system delivers precision, flexibility, and efficiency for professional inspection workflows.

Key Highlights

Industrial borescope camera system
360° full articulation inspection probe
1MP HD inspection camera
Optical fiber illumination for clear imaging
Multiple probe diameters (0.95mm to 6mm)
Flexible insertion tube (1m to 6m options)
6-inch HD industrial display with touch screen
Real-time video, image, and inspection recording
Interchangeable probe system for versatility
Wide viewing angle (up to 120°)
High-temperature resistance (-25°C to 80°C)
IP67 waterproof probe for industrial environments
HDMI, USB, and TF card connectivity
Wi-Fi wireless transmission (optional)
Long battery backup (8+ hours operation)
Portable handheld inspection system

Request a Quote

Get pricing, availability, and technical guidance.

Request Quote

Response within 1 business day.

Technical Specifications

Product Type	Industrial Borescope / Endoscope
Camera Resolution	1MP HD
Articulation	360° Full Direction
Viewing Angle	Up to 120°
Depth of Field (DOF)	3mm to infinity (varies by model)
Probe Diameter	0.95mm to 6mm
Probe Length	1m to 10m
Lighting	Fiber optic LED illumination
Probe Material	Tungsten braided flexible tube
Waterproof Rating	IP67
Display	6" Industrial LCD Screen
Display Resolution	1920 × 1080
Storage	TF Card (up to 128GB)
Connectivity	HDMI, Micro USB, Headphone
Battery	Replaceable battery system
Battery Backup	≥8 hours
Operating Temperature	-25°C to 80°C
System Weight	~3.9 kg

Applications

Gas turbine inspection

Aircraft engine inspection

Automotive engine inspection

Pipeline internal inspection

Heat exchanger inspection

Pressure vessel inspection

Request Product Information

Fill out the form below and our team will get back to you with detailed information about the AE-SGP Industrial Borescope.

Request a Quote

Interested in AE-SGP Industrial Borescope? Fill out the form below and our team will get back to you within 24 hours.

Frequently Asked Questions

What is the AE-SGP60 Industrial Borescope used for?▼

The AE-SGP60 is a handheld inspection camera for examining internal areas of engines, gearboxes, machinery and other industrial components during maintenance and quality checks.

Does the AE-SGP60 support 360-degree articulation?▼

Yes. Its probe supports 360-degree full-direction articulation, allowing operators to steer the camera tip toward different internal surfaces.

Can the AE-SGP60 inspect engine cylinders and gearboxes?▼

Yes. Where access is suitable, it can help technicians inspect cylinder walls, pistons, valves, gears and other parts for visible wear, deposits and surface damage.

Can the AE-SGP60 help find casting burrs and machining defects?▼

Yes. It can help locate visible burrs, machining marks and foreign material inside accessible castings and manufactured components.

What screen resolution and probe lengths does the AE-SGP60 offer?▼

It has a 6-inch display with 1920 x 1080 resolution. The standard probe specification lists a 1 MP camera, with insertion tube lengths from 1 m to 6 m.

Is the AE-SGP60 waterproof and suitable for plant maintenance?▼

The brochure specifies IP67 protection for the probe and IP54 for the controller. It is suitable for many industrial visual inspection tasks, but the whole unit should not be submerged.

Where can I buy a 360-degree articulating borescope in India?▼

Aerica Engineering Pvt. Ltd. offers the AE-SGP60 for maintenance, manufacturing and inspection applications. Contact sales@aericaengg.com for pricing and availability.
